Capacitive Touch Switch Module Intelligent Control Sensor Bistable State Sensitive Response for Nigh

Feature: 1. WIDE APPLICATION: Capacitive touch switch module can be used for LED light control, external relay, power switch, support external MCU 2. APPLICABLE MATERIAL: Capacitive touch sensor module can be used for acrylic glass, ceramic, plastic and other media surface, touch thickness is not more than 6mm 3. FUNCTION DESCRIPTION: Capacitive touch control module preset three pads, IN is power input +, GND is negative, OUT is power output 4. BISTABLE STATE TOUCH CONTROL: Touch sensor module can switch between standby mode and power on mode with a simple touch 5. SMART TOUCH SENSING: Intelligent touch sensor module possess high sensitivity and accuracy in detecting touch, ensuring reliable operation Specification: Item Type: Capacitive Touch Switch Module Material: PCB Input Voltage: DC 3-18V Standby Current: 5uA Input Current: 2.5A (maximum) Back Touch Sensing Maximum Sensing Distance: Approx. 6mm / 0.24in Preset Three Pads: IN = power input +, GND = negative, OUT = power output Standby State: The output voltage is zero, the LED light is off Power On: Output voltage = input voltage, the LED light is on Package List: 1 x Capacitive Touch Switch Module
