It has rated test voltages of 100V/250V/500V/1000V, a measurement range of up to 2000MΩ, and the ability to measure AC voltage.
Wide measuring range, with lock button, easy to select and use.
Can measure AC voltages of 500V or less (full-scale linear display).
A low resistance buzzer alarm encourages caution and observation.
The voltage status indicator (BATT CHECK light on) also functions as a high voltage indicator for insulation resistance tester operation.
Features: Rated test voltages of 100V/250V/500V/1000V, a measurement range of up to 2000MΩ, and the ability to measure AC voltage. A wide measurement range and a lock button make selection and use easy. A full-scale linear display allows measurement of AC voltages up to 500V. A low resistance buzzer alert encourages attention and observation. The voltage status indicator (BATT CHECK light) also functions as a high-voltage indicator for the insulation resistance tester's operation. A convenient external DC power (charging) socket is included. The wider dial design provides a wider display range, allowing for more accurate fault diagnosis. The dial illumination function allows accurate reading of measurements even in dimly lit areas. Automatic discharge function: To prevent electric shock due to residual charge in the circuit, the instrument automatically discharges after measurement. A powerful output load capacity with a maximum short-circuit current of 0.55mA is provided. The addition of a transistor withstand voltage measurement scale allows for direct reading of the withstand voltage value and load voltage of the device under test. It is a perfect test instrument for electricians, with complete functionality, higher accuracy, convenient and reliable operation. Comes with a pair of test and alligator clips, easy to carry.
It comes with a high-quality zipper bag for convenient storage and handling. It is used to measure the insulation resistance of various electrical equipment and insulating materials, such as transformers, motors, cables, switches, and electrical appliances, as well as for the maintenance, testing, and verification of well-known electrical equipment. Specifications: Material: ABS; Rated Test Voltage: 100V/250V/500V/1000V; Output Voltage: 90-120% of the rated test voltage; Output Short-Circuit Current: Max. 0.55mA Measurement Range: 0-2000M Transistor Withstand Voltage Measurement 100-1000V 0.5mA Discharge Resistance: 500k-5M Automatic Alarm: <2M (for 1000V) Voltage Measurement ACV 500V (50Hz) ACV Measurement Error: ±5% Detection: BATTLED Indication Insulation: Between Core Circuit and Case: >50M Operating Temperature/Humidity: 0~40°C, <75% (non-condensing) Storage Temperature/Humidity: -10~50°C, <85% Power Supply: 6 * 1.5V AA Batteries (Not Included) Product Size: 176 * 110 * 70mm / 6.93 * 4.33 * 2.76in Product Weight: 512g / 18.09oz Package Weight: 800g / 28.23oz Package Size
Size: 21.5 * 16.5 * 8cm / 8.46 * 6.50 * 3.15in Package List: 1 * Insulation Resistance Meter, 1 * Strap, 2 * Test Cables, 2 * Alligator Clips, 1 * Carrying Zipper Bag
