Through a WiFi connection, users can realtime realtime viewing of voltage, current, and power of each channel when generating and consuming kilowatts via APP to realize intelligent management. The APP displays realtime power, current, voltage, power factor, frequency, and electricity statistics for each channel in forward and reverse directions. With the power statistics function, you can view the daily, monthly, and yearly electricity via the cellphone Tuya APP and keep track of the power consumption at all times. With the automation function, you can set the power or current value in the APP.
Features:
Powerful Function & Intelligent Management: By adopting a WiFi connection and a highprecise measurement, realtime realtime viewing of voltage, current, and power of each channel when generating and consuming kilowatts via APP to realize intelligent management. It is mainly used in electrical systems, typically used in residential and small commercial settings.
Realtime Management: The APP displays realtime power, current, voltage, power factor, frequency, and electricity statistics for each channel in forward and reverse directions. With the power statistics function, you can view the daily, monthly, and yearly electricity via the cellphone Tuya APP and keep track of the power consumption at all times.
Automation Function: With the automation function, you can set the power or current value in the APP. When the power or current exceeds the set value, the device will initiate to work. With a calibration function, the device can be calibrated by adjusting the percentage.
Simple Operation: 35mm rail mounting, no need to replace wires connection, safer to use, just put the wires in the clip and measure.
Wide Applications: This can be particularly useful for managing energy consumption and cost, as well as for ensuring the safety and efficiency of the electrical system. Suitable for home appliance management, remote management, housing rental use, industrial control equipment use, intelligent upgrade of power distribution equipment, etc.
Specifications:
Name: Energy Meter
Material: PC
Type: 1CT, 2CT (optional)
Current measuring ranges: 0.2A80A
Input voltage: 110240 V, 5060Hz
Item size: 47 * 47 * 18mm 1.85 * 1.85 * 0.71in
Package size:
1CT: 100 * 100 * 30mm 3.94 * 3.94 * 1.18in
2CT: 115 * 115 * 40mm 4.53 * 4.53 * 1.57in
Package weight:
1CT: 150g 5.29ounce
2CT: 200g 7.05ounce
Packing List (1CT):
1 * Energy Meter
1 * CT
OR
Packing List (2CT):
1 * Energy Meter
2 * CT
