Main Function：Read Codes、Data Stream、DTC Lookup、Battery Test、Erase Codes、Freeze Frame、Oxygen sensor test、Tool Setup
Support for 12 languages：Traditional Chinese、Simplified Chinese、English、Korean、Japanese、German、Russian、Thai、Portuguese、Spanish、Arabic、French
Note: Automobile car OBD diagnostio instrument is suitable for gasoline cars that comply with the OBD2/EOBD standard protocol
Technical parameters:
Environment temperature: -40 °C - +80°C
Barometric press: 86- 106KPa
Relative humidity: 10%-95%
Environment voice: < =60dB
Alarm of sound level: > =30dB(A)
Work voltage :9V~ 16Vdc(12Vdc/400mA)
Color display: 1.77 inches
Supported Agreement：
SAE J1850 PWM（41.6 Kbaud）
SAE J1850 VPW（10.4 Kbaud）
IS09141-2(5 baud init, 10.4 Kbaud)
IS015765-4 CAN (11bit lD, 500 Kbaud)
IS015765-4 CAN (29bit lD, 500 Kbaud)
IS015765-4 CAN (11bit iD, 250 Kbaud)
IS015765-4 CAN (29bit iD, 250 Kbaud)
IS014230-4 KWP (fast init, 10.4 Kbaud)
IS014230-4 KWP (5 baud init, 10.4 kbaud)
Package Included:
1 x Car Diagnostic Tool
1 x English Manual
