6 in 1 Wall Metal Detector Backlight Wall Stud Finder AC Live Wire Cable Metal Detector LCD Display Electronic Wall Scanner

Battery Included : No High-concerned chemical : None Origin : Mainland China

Certification : CE,FCC,RoHS Model Number : HW-810 Handheld Wall Metal Detector DIY Supplies : Electrical With LCD Screen Or Not : Yes Power Type : Battery-Powered

6 in 1 Wall Metal Detector Backlight Wall Stud Finder AC Live Wire Cable Metal Detector LCD Display Electronic Wall Scanner Product Features: ·1/2"Stud Scan Mode:Detects wood or metal studs up to 13mm deep ·1"Stud Scan Mode:Detects wood or metal studs up to 25mm deep ·1 1/2"Stud Scan Mode:Detects wood or metal studs up to 38mm deep ·Metal Mode:Detects metal up to 80mm for magnetic(60mm for non-magnetic) deep ·AC Mode:Detects live unshielded AC wires up to 51mm deep ·Metal Depth Indicator ·Green Backlight .Low Voltage Indicator ·Battery Type:9V battery(6F22) ·Operating Current:<50ma ·Shutdown Current:<10UA ·Automatic Shutdown Time:3 minutes

Specifications: Model: HW-810 Authentication: CE FCC RHOS Packaging size: 186 * 75 * 44MM Weight: 175G Battery: 9V battery 6F22 (not included) Purpose: Quickly locate wood, metal, and AC wires hidden in the walls, floors, and ceilings of a house. It can work in Flat noodles, wallpaper, wood floor, acoustic ceiling, spray painted wall and other places. Prevent you from encountering danger when installing televisions, cabinets, garage racks, etc.

Detection Mode: Stud Mode: In stud mode, there are 3 scan modes o choose for properly thick of the scanning surface: *1/2"Scan Mode can detect 1/2 in. (13mn) deep. *1"Scan Mode can detect 1 in. (25mm)deep. *1 1/2"Scan Mode can detect 1 1/2 in.(38mm) deep. If you don't know the depth of the detection, it is recommended to use 1/2"scan mode first. When 1/2"scan mode is not detected, use 1"or 1 1/2"scan mode instead. Metal Mode: The detection of magnetic metal can be as deep as 3.2 in. (80mm)(diameter 15mm galvanized steel tube) It can detect non-magnetic metals up tc 2.4 in. (60mm) (diameter 13mm copper tube). AC Mode: Detect unshielded AC live wire up to 2 in. (51mm) deep.
