Feature:
1. PWM solar controller, with dual reverse current protection, low heating generation.
2. Support 12V 24V automatic identification, ultra‑wide charge and discharge adjustable.
3. Designed for charging ‑acid, ternary lithium, and lithium iron phosphate batteries.
4. Built‑in short circuit protection, open circuit protection, reverse connection protection, overload protection.
5. Battery charge controller, rated charging current is 40A and rated discharge current is 20A.
Specification:
Item Type: Solar Charge Controller
Material: Plastic
Weight: Approx. 145g 5.1oz
Product Size: Approx. 13.3x7cm 5.2x2.8in
System Voltage
12V 24V automatic recognition (no power storage function)
Rated Charging Current
40A
Rated Discharge Current
20A
Battery Type
Maximum Photovoltaic Voltage
When the battery is 12V, the maximum voltage is 23V, when the battery is 24V, the maximum voltage is 46V
Battery Type
acid battery lithium ion battery (ternary lithium) lithium iron phosphate battery
Charging Cut Off Voltage
Acid Batteries
The default value is 14.4V (not adjustable)
Ternary Lithium Battery
The default value is 12.6V (not adjustable)
Lithium Iron Phosphate Battery
The default value is 14.6V (not adjustable)
Discharge Recovery Voltage
Acid Batteries
The default value is 12.6V (adjustable 11.5V 13V)
Ternary Lithium Battery
The default value is 10.5V (adjustable 10V 11V)
Lithium Iron Phosphate Battery
The default value is 12.0V (adjustable 11.5V 12.5V)
Discharge Cut Off Voltage
Acid Batteries
The default value is 10.7V (adjustable from 9.5V to 11.5V)
Ternary Lithium Battery
The default value is 9.0V (adjustable from 8.5V to 9.5V)
Lithium Iron Phosphate Battery
The default value is 10.0V (adjustable from 9.5V to 10.5V)
Float Voltage
Acid Batteries
The default value is 13.7V (adjustable from 13V to 15V)
Ternary Lithium Battery
The default value is 12.0V (adjustable 11.5V 12.5V)
Lithium Iron Phosphate Battery
The default value is 13.8V (adjustable from 13V to 14.5V)
USB Output
2 USB Outputs, Maximum 5V 2A
Stand By Current
<10mA
Operating Temperature
35 celsius +60 celsius
Please note that the voltage in the example is only for the 12V system, if you use the 24V system, please multiply by 2..
Package List:
1 x Solar Charge Controller1 x Manual
